珠海海奇代理商A/B/C/D/E系列产品性能参数选型表

作者:bwin必赢发布时间:2024-03-05

珠海海奇代理商

        海奇芯片在多媒体SOC 领域拥有深厚的技术积累和市场理解,产品已广泛应用于消费电子、车载终端、商用显示以及投影等跨屏协同场景。在“算、显”分离领域是少数既掌握核心芯片设计研发技术又掌握智能设备互联软件协议的公司,在IC 和应用系统设计方面拥有自己的特色。

海奇产品由多个系列组成:

A系列产品主要应用于多屏互联、算显分离领域,该系列产品线也广泛应用于家庭多媒体播放器、卡拉OK 等产品;

B系列产品主要应用于带屏类商用显示产品,包含便携式播放器、车载多媒体中控、电子贺卡、数码相框、广告机、电子水牌、HMI 人机交互等多个领域;

C 系列可应用于对屏幕分辨率要求较高的商显市场,可支持4K 级解码和显示;

D 系列产品支持HDMI 输入并可驱动RGB/LVDS/MIPI 等主流屏幕接口,可用于投影仪、3D打印、商用电视、专用显示器等市场;

E 系列是海奇独有的多显接口类产品,可在支持HDMI 高清接口输入输出的同时,支持主流屏幕输出接口,典型应用包含卡拉OK 点唱机、会议设备等。

A系列产品

Part No. A111 A210C/A211C A3000 A3100 A3200 A3300(A300) A5000 A5100 A5200
CPU 800MHz 800MHz 1.0GHz 1.0GHz 1.0GHz 1.0GHz 1.2GHz 1.2GHz 1.2GHz
DRAM 64MB  SIP ext.  max. 256MB @800Mbps 128MB  SiP@1600Mbps ext.  max. 256MB @1333Mbps ext.  max. 256MB @1333Mbps ext.  max. 256MB @1333Mbps 128MB  SiP@1600Mbps ext.  max. 256MB @1333Mbps ext.  max. 256MB @1333Mbps
Flash SPI  Flash SPI  Flash SPI  Flash SPI  Flash SPI  / NAND SPI  Flash SPI  / NAND SPI  Flash SPI  / NAND
Video Decoder Multi-format @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS H.264@4K  30FPS H.264@4K  30FPS H.264@4K  30FPS
Display HDMI  V1.4+VGA HDMI  V1.4 HDMI_TX/VGA/CVBS HDMI_TX  VGA HDMI_TX/VGA HDMI_TX  VGA HDMI_TX/VGA/CVBS HDMI_TX  VGA HDMI_TX/VGA
Video Input N/A CCIR601/656 N/A N/A HDMI  V1.4 HDMI1.4  /CVBS HDMI1.4  /CVBS N/A HDMI  V1.4
Audio I2S  in+out/SPDIF out I2S  in+out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out
USB USB2.0 USB2.0 USB2.0x2 USB2.0x2 USB2.0x2 USB2.0x2 USB2.0x2 USB2.0x2 USB2.0x2
    HOST/Slavex2     HOST/Slavex2
SDIO SDIO2.0 SDIO2.0 SDIO3.0/eMMC4.4 SDIO3.0 SDIO3.0/eMMC4.4 N/A SDIO3.0/  EMMC4.4(4line) SDIO3.0 SDIO3.0/eMMC4.4
    1data~4Data     1data~5Data
I2C/UART 2xI2C+2xUart,  IRRX 2xI2C+3xUart,  IRRX 2xI2C+2xUart,  IRRX 3xI2C+2xUart,IRRX 3xI2C+2xUart,IRRX,  SAR ADCx2 3xI2C+2xUart,IRRX Support  6xPWM 2xI2C+2xUart, IRRX 3xI2C+2xUart,IRRX 3xI2C+2xUart,IRRX,  SAR ADCx2
    ,4xTPADC, 1xSARADC
Ethernet N/A N/A Support  USB to Ethernet RMII RMII N/A RMII RMII RMII
Wi-Fi A110  Support A210C  Support Support Support Support Support Support Support Support
SW System RTOS RTOS RTOS Linux/RTOS Linux/RTOS Linux/RTOS RTOS Linux/RTOS Linux/RTOS
Package QFN68 ELQFP128 QFN68 eLQFP128 ELQFP176 eLQFP128 eLQFP128/QFN128 eLQFP128 ELQFP176



B、C系列产品

Part No. B100 B200 B3100 B3200 C3000 C3100 C3200 C5000 C5200
CPU 800MHz 800MHz 1.0GHz 1.0GHz 1.0GHz 1.0GHz 1.0GHz 1.2GHz 1.2GHz
DRAM 64MB  SIP ext.  max. 256MB @800MHz max.256MB  ext. max.256MB  ext. 128MB  SiP@1600Mbps max.256MB  ext. max.256MB  ext. 128MB  SiP@1600Mbps max.256MB  ext.
    1333Mbps     1333Mbps     1333Mbps     1333Mbps     1333Mbps
Flash SPI  Flash SPI  Flash SPI  Flash SPI  / NAND SPI  / NAND SPI  Flash SPI  Flash SPI  / NAND SPI  Flash
Video Decoder Multi-format @FHD 60fps Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS H.264@4K  30FPS H.264@4K  30FPS
Display RGB888+CVBS RGB888 RGB565/LVDS/CVBS RGB888/LVDS/CVBS RGB565/MIPI/LVDS/CVBS MIPI/CVBS RGB888/MIPI/LVDS RGB565/MIPI/LVDS/CVBS RGB888/MIPI/LVDS
Video Input CCIR601/656 CVBS N/A CCIR601/CCIR656/  CVBS CVBS CCIR601/CCIR656/  CVBS CCIR601/CCIR656/  CVBS CCIR601/CCIR656/  CVBS
Audio I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM out/SPDIF out I2S  in+I2S out/2ch PCM I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out
    out/SPDIF out
USB USB2.0x2 USB2.0x2 USB2.0x2 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0
    Host/Slave     Host/Slave     Host/Slave     Host/Slave     Host/Slave
SDIO SDIO2.0 SDIO2.0 SDIO3.0/  EMMC4.4(4line) SDIO3.0/eMMC4.4 SDIO3.0/  EMMC4.4(4line) SDIO3.0/  EMMC4.4(4line) SDIO3.0/eMMC4.4 SDIO3.0/  EMMC4.4(4line) SDIO3.0/eMMC4.4
    1data~4Data     1data~4Data
I2C/UART Support 2xI2C+2xUart,support IR receiver 3xUART,4xTPADC, 2xI2C+3xUart,T,4xTPADC, Support  6xPWM, 3xUART,4xTPADC, Support  6xPWM, 3xUART,4xTPADC, Support  6xPWM, 3xUART,4xTPADC, Support  6xPWM, 3xUART,4xTPADC, Support  6xPWM, 3xUART,4xTPADC,
    1xSARADC,IRRX     1xSARADC     1xSARADC,IRRX     2xSARADC IRRX     2xSARADC IRRX     1xSARADC,IRRX     2xSARADC IRRX
Ethernet N/A N/A N/A RMII RMII N/A RMII RMII RMII
Wi-Fi Support B200/B200C Support Support Support Support Support Support Support
    Support
SW System RTOS RTOS RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux
Package QFN88 ELQFP128 eLQFP128 QFP176 eLQFP128 eLQFP128 eLQFP176 eLQFP128 eLQFP176



D、E系列产品

Part No. D3000 D3100 D3101 D3200 D5000 D5200 E100 E3000 E3100
CPU 1.0GHz 1.0GHz 1.0GHz 1.0GHz 1.0GHz 1.2GHz 800MHz 1.2GHz 1.2GHz
DRAM 128MB  SiP@1600Mbps max.256MB  ext. max.256MB  ext. max.256MB  ext. 128MB  SiP@1600Mbps max.256MB  ext. 64MB  SiP@1066Mbps 128MB  SIP@1600Mbps max.256MB  ext.
    1333Mbps     1333Mbps     1333Mbps     1333Mbps     1333Mbps
Flash SPI  Flash SPI  Flash SPI  Flash SPI  Flash SPI  Flash SPI  Flash SPI  Flash SPI  Flash SPI  / NAND
Video Decoder Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS Multi-format  @FHD 60FPS H.264@4K  30FPS H.264@4K  30FPS Multi-format  @FHD 60FPS H.264@4K  30FPS H.264@4K  30FPS
Display RGB888/MIPI/LVDS/CV  BS RGB565/LVDS RGB565/LVDS RGB888/MIPI/LVDS/CV  BS RGB888/MIPI/LVDS/CV  BS RGB888/MIPI/LVDS/CV  BS RGB888/HDMI HDMI1.4/RGB/MIPI/LV  DS HDMI1.4/RGB888/LVDS
    /MIPI/VGA
Video Input HDMI1.4  /CVBS HDMI1.4  /CVBS HDMI1.4  /CVBS HDMI1.4  /CVBS HDMI1.4  /CVBS HDMI1.4  /CVBS N/A   DVP/CSI2.0/HDMI1.4
    /CVBS
Audio I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+I2S out I2S  in+out/SPDIF out I2S  in+I2S out/SPDIF out I2S/4DMIC  in &I2S 7.1
    out
USB USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  Host+USB2.0 USB2.0  HOST/Slavex2 USB2.0x2 USB2.0x2
    Host/Slave     Host/Slave     Host/Slave     Host/Slave     Host/Slave     Host/Slave
SDIO SDIO3.0/  EMMC4.4(4line) SDIO3.0/  EMMC4.4(4line) SDIO3.0/  EMMC4.4(4line) SDIO3.0/  EMMC4.4(4line) SDIO3.0/  EMMC4.4(4line) SDIO3.0/  EMMC4.4(4line) SDIO2.0 SDIO3.0/eMMC4.4 SDIO3.0/eMMC4.4
I2C/UART Support  6xPWM, 3xUART,4xTPADC, Support  6xPWM, 2xUART 1xSARADC Support  6xPWM, 2xUART 1xSARADC Support  6xPWM, 3xUART, 1xSARADC Support  6xPWM, 3xUART,4xTPADC, Support  6xPWM, 3xUART, 1xSARADC Support  2xI2C+2xUart,support Support  6xPWM, 3xUART, 2xSARADC Support  6xPWM, 3xUART,4xTPADC,
    1xSARADC,IRRX     IRRX     IRRX     IRRX     1xSARADC,IRRX     IRRX     IR receiver     IRRX     2xSARADC
Ethernet RMII N/A N/A RMII RMII RMII N/A N/A 100/1000M  RMII
Wi-Fi Support Support Support Support Support Support Suppport Support Support
SW RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux RTOS/Linux ROTS RTOS/Linux RTOS/Linux
    System
Package eLQFP128/QFN124 eLQFP128 eLQFP128 eLQFP176 eLQFP128 eLQFP176 QFN124 eLQFP128 QFP216

珠海海奇半导体产品典型应用

海奇代理商,欢迎咨询,辅助选型号,提供芯片和方案,还有更多精彩产品方案分享《海奇B3100多媒体应用处理器应用在车载多媒体,网络数码相框,网络广告机,游戏机,带屏音响,智能投影仪》《商业显示-手机同屏器方案》。
